i:SY XXL E5 ZR F CX
i:SY XXL E5 ZR F CX – Built for Power & Performance!
Designed for taller riders (up to 210 cm) and optimized for high load capacity (180 kg), the i:SY XXL E5 ZR F CX is a true powerhouse.
Key Features:
-
BOSCH Performance Line CX motor (85 Nm) for maximum power
-
SHIMANO Nexus 5-speed hub gearing for smooth shifting
-
GATES® CDX CenterTrack belt drive for durability & efficiency
-
BOSCH Smart System for full smartphone integration via the ebike Flow app
-
Speedlifter Twist handlebar with 90° rotation for easy storage
-
i:SY front luggage rack & frame lock with quick release
-
Foldable pedals for compact storage
This XXL e-bike delivers agility, precision, and premium riding comfort
Add an accessory to your bike
Select your favourite bag or rack from our catalog!
Couldn't load pickup availability
Ride it! Love it!
The i:SY principles
Product Specifications
Performance & Motor
Motor: Bosch Performance Line CX 25/85Nm
Manufacturer: Bosch
Assistance: Up to 25 km/h
Battery: Bosch PowerPack 545 (545 Wh)
Display: Bosch Kiox 500
Frame & Components
Frame: Original i:SY XXL Unisex
Material: Aluminium
Fork: Original i:SY Starrgabel
Gearing & Braking System
Gears: 5-speed hub transmission
Shifter: SHIMANO Nexus Revo Shifter
Crankset: i:SY E-bike crank
Cassette: 28T
Brakes: Hydraulic disc brakes
Front: TEKTRO HD-T532 (4 pistons)
Rear: TEKTRO HD-T532 (2 pistons)
Brake Discs: 180 mm (front), 160 mm (rear)
Brake Levers: 3-finger
Wheels & Tires
Front & Rear Rims: RYDE Andra 40 Disc, 32H
Front Hub: Shimano Deore HB-M5100
Rear Hub: Shimano Inter-5E, SG-C7000-5D
Spokes: 32x Niro 2.0 mm
Tires: SCHWALBE Pick Up, Super Defense
Tire Size: 20 x 2.35 inch (ETRTO: 60-406)
Handlebar & Saddle
Handlebar: i:SY 30°
Grips: ERGON GC10 ergonomic grips
Stem: i:SY Stem 70mm
Headset: i:SY Steuersatz
Saddle: ZECURE, Hydro Foam, size L
Seatpost: i:SY Seatpost, 415 mm, ⌀ 34.9 mm
Seat Clamp: i:SY 1.0 integrated
Additional Features
Pedals: i:SY anti-slip folding pedals
Lights:
Front: FUXON FF-100EB (100 Lux LED high beam)
Rear: FUXON R-Glow S LED rear light
Kickstand: PLETSCHER Kickstand Comp40 Flex
Mudguards: SKS Bluemels (20-inch, width 65 mm)
Luggage Rack: i:SY Bagagedrager, MonkeyLoad-ready
Chain Guard: HORN Catena
Locks: Abus i:SY-Set XPlus (battery & frame lock, BLO BOS DT3 + 4750SL NR)
Technical Specs
Wheel Size: 20 Inch
Frame Height: 51 cm
Colors Available: Opal Green, Berry Red, Happy Orange, Pepper Black, Cosmos Blue
Maximum Load Capacity: 180 kg
Bike Weight: 23.9 kg
Charger: Bosch 4 Ah
