i:SY XXL P12 ZR
Innovation! The XXL P12 ZR with PINION M.G.U. – Motor and Gearbox in One Unit Our ultimate XXL powerhouse is equipped with the revolutionary Motor.Gearbox.Unit from PINION, seamlessly combining motor and gearbox into a perfectly synchronized system. The 12-speed transmission...
Book a test rideDescription
Innovation! The XXL P12 ZR with PINION M.G.U. – Motor and Gearbox in One Unit
Our ultimate XXL powerhouse is equipped with the revolutionary Motor.Gearbox.Unit from PINION, seamlessly combining motor and gearbox into a perfectly synchronized system. The 12-speed transmission offers an impressive 600% gear range, paired with 85 Nm of pure motor power. With an 800 Wh battery, no distance is too far and no mountain too steep.
-
Powerful PINION M.G.U. mid-motor with 85 Nm torque and integrated 12-speed gearbox
-
Compact core with 800 Wh battery capacity
-
Includes i:SY front luggage rack and frame lock with quick release
Specifications
i:SY XXL P12 ZR
Product Details
Model Year: 2025
Motor: FIT PINION MGU E1.12
Motor Manufacturer: Pinion
Motor Assistance: Up to 25 km/h
Battery: FIT CompactCore 800 (800 Wh)
Display: FIT Comfort, 3.5 Inch
Frame & Suspension
Frame Specification: Original i:SY XXL 2.0 unisex, thru-axle
Frame Material: Aluminum
Front Fork: Original i:SY rigid fork 2.0, thru-axle
Gears & Brakes
Number of Gears: 12-speed
Gear System: Integrated bottom bracket transmission
Shifter: FIT remote control Basic E-Shift
Crankset: i:SY E-bike crank
Cassette: 24T
Brake Type: Hydraulic disc brake
Front Brake: Magura MT-C, 4-piston
Rear Brake: Magura MT-C, 2-piston
Brake Lever: 3-finger brake lever
Rear Brake Lever: 3-finger brake lever
Brake Disc (Front): 180 mm
Brake Disc (Rear): 160 mm
Wheels & Tires
Rims: Ryde Disc30 (front and rear)
Front Hub: FORMULA DC-71, 6-bolt, 15mm TA
Rear Hub: FORMULA EHL-51, 6-bolt, 12mm TA
Spokes: 32x Niro 2.0 mm
Tires: SCHWALBE Pick Up, Super Defense
Tire Size (inch): 20 x 2.35
Tire Size (ETRTO): 60-406
Steering & Seat
Handlebar: i:SY handlebar 30°
Grips: ERGON GC10 ergonomic grips
Stem: i:SY stem 70 mm
Headset: i:SY Steuersatz
Saddle: ZECURE, Hydro Foam, size L
Seat Post: i:SY seat post, 415 mm, Ø 34.9 mm
Seat Clamp: i:SY 2.0 quick release integrated
Accessories
Pedals: i:SY anti-slip folding pedal
Front Light: FUXON FF-100EB, 100 Lux LED with high beam
Rear Light: FUXON R-Glow S LED rear light
Kickstand: PLETSCHER Kickstand Comp40 Flex
Mudguards: i:SY aluminum mudguard, 20 inch, width 70 mm
Luggage Rack: i:SY Luggage Rack 2.0, MonkeyLoad-ready
Chain Guard: i:SY chain protector
Locks: Abus i:SY-Set XPlus keyed alike (battery and frame lock)
Dimensions & Weight
Wheel Size: 20 Inch
Frame Height: 51 cm
Colors Available: Seashell White, Ice Silver, Berry Red, Pepper Black, Cosmos Blue
Maximum Permitted Weight: 180 kg
Bike Weight: 25.9 kg
Charger: FIT Charger 3 Ah
